Application
Telecommunication
networks
CATV-cable
television network
FTTH-Fiber
to the home
Protect
and house fiber splices and joints between optical cables
Cable
un-cut through and branching, cable splices and branching
Feature
In
accordance with international standards
IP68
protection and IK10 impact strength
Applicable
for aerial, pipeline and manhole usage
Mechanic
sealing cable entries
Specification
Maximum External Dimensions
560*240*130mm
Maximum Splice Capacity
288 splices, 48 splices per splice tray
Cable Entries
6 entries
Cable Diameters Range
8~18mm
Material
PC material (Body, Cover)
ABS material(Splice Tray)
Stainless Steel(Metal Parts)
Operating Temperature
-40~+65¡æ
Relatively Humidity
¡Ü93%£¨+40¡æ£©
Atmosphere
70~106Kpa
Outer Carton
70*51*45cm, 33kg, 6 pcs/carton
