Application
Telecommunication networks
CATV-cable television network
FTTH-Fiber to the home
Access point between distribution cable and drop cable
Feature
In accordance with international standards
IP65 protection and IK10 impact strength
Applicable for aerial and pole-mount usage
3 layer structure, easy to maintain
Specification
|
Maximum External Dimensions |
285*175*110mm |
|
Maximum Splice Capacity |
24 splices |
|
Splitter Installation |
1 set 1x16 PLC splitter or 2 sets 1x8 PLC Splitter |
|
Cable Entries |
2 entries (8~16mm) 4 entries (8mm) 16 entries (Drop Cable 2*3mm, 2*5mm, 3.5mm) |
|
Material |
PP*Glassfiber material(Body) ABS material(Splice Tray) Stainless Steel(Metal Parts) |
|
Operating Temperature |
-40~+65¡æ |
|
Relatively Humidity |
¡Ü93%£¨+40¡æ£© |
|
Atmosphere |
70~106Kpa |
|
Outer Carton |
62*31*42cm, 18kg, 10 pcs/carton |
